Battery Size:200ah
Battery Type:Sealed
Weight:54.5kg
Storage Type:sealed
The charging ratio:96%
The discharge rate:80%
Container Material:Strong ABS
Plates:Lead-Tin- Calcium-Aluminum alloy grids
Electrolyte:Sulfuric Acid Thixotropic
Separators Type:Absorbent Glass Mat (AGM)

Xingao battery has advantages and features compared with general batteries:

1、Good safety performance: no electrolyte leakage, no battery swelling and cracking under normal operation.

2、Good discharge performance: smooth discharge voltage and steep discharge channel.

3、good resistance to vibration: thoroughly charged battery completely fixed with 4mm amplitude, 16.7Hz frequency vibration for 1

hour, no leakage, no battery swelling and cracking, open circuit voltage is normal.

4、Good impact resistance:thoroughly charged battery from 20cm high natural fall to 1cm thick hardwood board 3 times. No leakage,no battery expansion and cracking, open-circuit voltage is normal.

5、good resistance to over discharge: 25 degrees Celsius, completely charged battery for 3 weeks of fixed resistance discharge

(resistance value equivalent to the battery 1CA discharge resistance requirements) recovery capacity of 75% or more.

6、good resistance to overcharge: 25 degrees Celsius, completely charged battery 0.1CA charge for 48 hours, no leakage, no battery

swelling and cracking, open circuit voltage is normal, capacity retention rate of 95% or more.

7、Good resistance to high current: 2CA discharge for 5 minutes or 10CA discharge for 5 seconds for a thoroughly charged battery.No

conductive part fuse, no appearance deformation.




Nominal Voltage
12v
Rated capacity ( 20 hour rate)
65Ah



Dimensions
Length
350士2mm( 13.78inch)
Width
166士2mm(6.54inch)
Height
179士2mm( 7.05inch)
Total Height
179士2mm( 7.05inch)
 Approx. Weight
21kg(46.3lbs)士3%


           Capacity

(25℃)
10HR(10.8v)
65Ah
3HR(10.8v)
48Ah
1HR(10.5V)
36Ah
Terminal type
T14
Internal resistance
(Fully charged,25℃)
pprox.7m Ω



    Capacity affected by temperature (20HR)

40℃
102%
25℃
100%
0℃
85%
-15℃
65%
Self-discharge (25℃)
3 months
Remaining Capacity:91%
6 months
Remaining Capacity:82%
6 months
Remaining Capacity:65%
Nominal operating
temperature
25℃士3C(77°F士5°F)



Operating temperature

range
Discharge
-15℃~50 ℃(5°F~122°F)
Charge
-10℃~50 ℃(14°F~122°F)
Storage
-20℃~50℃(-4°F~122°F)
Float charging voltage(25℃)
13.50 to 13.80v
Temperature compensation:-18mv/℃
Cyclic charging voltage(25℃)
14.50 to 15.00v
Temperature compensation:-30mvrc
Maximum charging current
13A
Maximum discharge current
650A(5 sec.)
Designed floating life(2orc)
12years
